Description
Features and Specs
Features
- Rated #1 By Professional R&D Technicians
- Gray Manufacturing Crafted Transmission Jack Adapters For Multiple Transmissions
- Acme Threaded Screws
- Two-Stage Design
- Made In The U.S.A.
Specifications
- Capacity: 1,200 lbs. (544.31kg)
- Minimum Start Height: 34 1/2″ (87.63cm)
- Maximum Lift Height: 72″ (182.88cm)
- 1st Stage Power: Air
- 2nd Stage Power: Hydraulic
- Head Plate Dimensions: 11 1/2″ x 11 1/2″ (29.21 x 29.21cm)
- Overall Width: 41″ (104.14cm)
- Overall Length: 41″ (104.14cm)
- Swivel Caster Diameter: 4″ (10.16cm)
- Required Air Pressure: 90-160 PSI (6.2-11 BAR)
- Tilt Forward: 40°
- Tilt Rear: 20°
- Tilt Side: 10°
- Shipping Weight: 125 lbs. (56.70kg)
